$120.00Special Offer
Secure Storage Holder 80NB (Holds 2) Model: SSH280
Original price was: $165.00.$120.00Current price is: $120.00.
Secure storage holder to suit 80NB locking removable bollards. Available with masonry anchors.
Holds 2 bollards 88.9mm OD
Size: L230 x W120 x H150mm
Fixing Type: Masonry Anchor
Finish: Powdercoated
Colour: Black
Ordering / Specification model: SSH280
Secure storage holder to suit 80NB (88.9mm Outside Diameter) locking removable bollards. Available with masonry anchors.
Holds 2 bollards
Suits all LAPS Impact Security SPT90R, VOG80R, VOGC80R, Spartan 80NB (88.9mm OD) locking and removable bollards,Vogue Stainless steel 80NB (88.9mm OD) Also suitable for Leda Securapost Removable steel and stainless steel bollards. 88.9mm OD bollards such as the XP90R, SP90R, SSP80R, SSR80R
L230 x W120 x H150mm overall
You may also be interested in
Standard Duty cover plate to suit existing 77-90mm ground holes. To be used when bollards are removed from the ground hole position. Ideal for pedestrian and light traffic areas. If you require the heavy duty model, the part number is HDCP80
Covers one 77-90mm hole, can be used for all 88.9mm / 90mm Impact Security ® removable bollards, Securapost 90mm removable bollards including Vogue stainless steel models.
Ordering details : SDCP80
Dimension of product: lower body that sits in hole is 75mm diameter. (designed to fit holes from 77mm – 90mm)
Designed for light pedestrian and low traffic areas.
Top flat section 150mm diameter with a 3mm profile. (ideal for forklifts and pedestrian areas)
Cover plate to suit existing 170mm holes. To be used when bollards are removed from the ground hole position.
Covers one 170mm ground hole, can be used for all 150NB Impact security bollards including stainless steel bollards.
Dimentions of product: lower body that sits in hole is 165mm diameter. (designed to fit holes from 165-170mm)
Specification / Ordering details : SDCP150
Top flat section that sits on top of concrete is 200mm diameter
LAPS high security bollards / Hostile Vehicle Mitigation Bollards (HVM) PAS68 rated.
Ideally suited for protecting entry points to large commercial buildings and government facilities against acts of terrorism.
Shallow Mounted Bollard Systems.
A shallow mount bollard system can be installed in concrete ranging from 305mm to 406.4mm depending on the level of protection required.
Fixed Or Removable Bollard Design
FB30(fixed)Â / RB30 (Removable)
Shallow Mount Fixed Bollard
Fixed in Situ bollard.
Engineered To Meet US Marshall Service Standards /PAS68 rated for 7.5T @ 80km/hr, must be installed to our specified engineered footing in an array of 5 or more bollards.
– PAS68: V/7,500(N2)/80/90:5/14
– Allowance made for Stainless Steel Sleeves – Marine Grade 316 Linished Level 4 finish
– Footing Depth – 150mm + Blinding Slab + 100mm allowance for FFL (Shallow mount Foundation)
1016mm Above Ground Bollard Height, – Bollard Diameter 203.2mm
Custom Decorative Colours Available or stainless steel marine grade 316 finish, level 4
Shallow Mount Removable Bollard
Engineered to perform against an impact of up to 7.5T @ 64km/hr, must be installed to our specified engineered footing in an array of 3 or more bollards.
– 305mm diameter
– Allowance made for Stainless Steel Sleeves – Grade 316 Linished Level 4 finish.
– Footing Depth – 112mm Shallow Foundation Plate & 280mm Socket + 100mm allowance for FFL
The Maverick lighting bollard range provides an alternative style to the commercial range of bollards.
Manufactured as a lighting bollard from aluminium, it can be matched with our fixed and locking removable range to provide a uniform consistency on your project.
For installations that require impact rated security bollards, we have the HIT (high impact threat) range of bollards, these can be covered with a polyethylene sleeve in the maverick design.
See Resources and Downloads tab for additional information.
